Orange Pi 800 Development Board 4GB RAM 64GB EMMC 64bit Rockchip RK3399 SoC Support 4K 2.4G/5G Dual Band WiFI BLE Portable Keyboard

CPU: RK3399 1.8GHz 2-core A72 1.4GHz 4-core A53

GPU: ARM Mali-T860MP4

RAM: 4GB (LPDDR4)

Onboard storage: TF card slot, 64GB eMMC Flash

Ethernet: 10M/100M/1000M(YT8531C)

WiFi+bluetooth:

• On-board module (CDW-20U5622),

•2.4GHz/SGHz dual-band WiFi, support IEEE 802.11a/b/g/n/ac protocol:

• bluetooth 5.0. BLE support

Video output: HDMI 2.0*1, VGA*1

Audio output: 3.5mm headphone jack; HDMI 2.0*1; speaker

audio input

• Onboard MIC, onboard analog audio input,

• 1* Headset: 3.5mm headphone jack, audio input and output

Keyboard: 78-key QWERTY keyboard

USB port: USB2.0 *1; USB3.0 *2

Power supply: USB Type C interface input 5V4A

26Pin interface: with I2C*1, SPI, UART and multiple GPIO ports

LED lights: power indicator, keyboard Caps key and Num key indicator

Supported operating systems: Open source Hongmeng, Orange Pi OS, Android12.1, Manjaro, Ubuntu22.04, Debian11

Dimensions: 286mm X 122 mm X 22 mm

Weight: 385g

1. Light, efficient and free

2. Low power consumption, low heat generation, low noise, and supports the needs of various office scenarios

3. Plug and play, fast screen projection, multitasking without lag, more efficient than mobile phones and more portable than computers, allowing you to "work anytime, anywhere

4. Small size, high integration, low power consumption, stable operation; 64-bit 6-core processor, 4GB RAM, high performance is competent for specialized industrial automation tasks

5. Multiple operating systems are convenient for users to carry out secondary development

1×Orange Pi 800 Development Board
