1/2/4/6/8/16 Relay Module 8 Channel with Optocoupler Relay Output 1 2 4 6 Relay Module 8 Channels Low Level Trigger 5/12/24V
- Stock: In Stock
- Model: ST230042792
- SKU: ST230042792
$3.99
Ex Tax: $3.99
Specifications:
Voltage version:-----5V-------------12V-------------24V
Quiescent Current: 4mA-----------5.5mA----------12mA
Working current:---65mA-----------42mA----------40mA
Trigger voltage:-----0-2V------------0-4V-----------0-12V
Trigger current:-----2mA------------3mA-----------3mA
Relay contact capacity: 250V 10A (AC) or 30V 30A (DC)
Package Included:
1 x 5V/12V 24V 1/2/4/6/8/16 Relay Module
