CHF-GM12-N20VA 6/12V 8/15rpm Gear Motor Permanent Magnet DC Gear Reduction Motor
- Stock: In Stock
- Model: ST220012453
- SKU: ST220012453
$13.99
Ex Tax: $13.99
Descriptions:
Chihai CHF-GM12-N20VA 6/12V 8/15rpm gear motor permanent magnet DC gear reduction motor
Specifications: Brand: Chihai Motor
Model: CHF-GM12-N20VA Permanent Magnet DC Gear Reduction Motor
Specifications: Brand: Chihai Motor
Model: CHF-GM12-N20VA Permanent Magnet DC Gear Reduction Motor
| Type | Use voltage | Motor model | Reduction ratio | No load | Rated | Blocking | |||||
| Current | Speed | Torque | Speed | Current | Current | Torque | |||||
| A | DC6.0V | A05 | 1:1000 | ≤30mA | 8rpm | 2.50Kg.cm | 0.25N.m | 5rpm | ≤0.08A | ≤0.2A | ≥4.0Kg.cm |
| B | DC12.0V | ≤40mA | 15rpm | 12rpm | ≤0.1A | ≤0.3A | |||||
Note:
The reduction ratio is 1:1000, the deceleration is relatively large, causing the torque of the whole machine to be too large.
It should not exceed the rated torque of 2.5kg.cm, and it is forbidden to block or externally give the opposite direction of operation.
Features: - Permanent magnet DC gear reduction.
- Two Types to meet your different needed.
Package Included: 1 x Gear Motor
More Details:
It should not exceed the rated torque of 2.5kg.cm, and it is forbidden to block or externally give the opposite direction of operation.
Features: - Permanent magnet DC gear reduction.
- Two Types to meet your different needed.
Package Included: 1 x Gear Motor
